READY TO RACE OUT OF THE BOX, THE MYST PRO IS HERE FOR AS MANY LAPS AS YOU CAN CRAM INTO THE DAY.
-
DESCRIPTION
Built for the privateer racer, the Myst Pro is made to be hauled across the country and smashed down the nastiest downhill tracks.
Featuring the same Factory Team developed frame as the top model, the Pro is equally at home strapped to the back of an uplift trailer, or enjoying the once-a-year luxury of a chairlift in the Alps.
So what’s changed? We’ve moved the shock to get the centre-of-gravity as low as possible for that planted feeling. And we’ve created a new link.Our Tuned Ride link allows the suspension to be more active under braking, giving more traction when you need it most.
Taking care of the heavy hits out back is the Marzocchi Bomber CR coil. Sensitive enough to deal with the chatter, and happy to deal with those high-speed G-outs or huck-to-flats.
Up front the RockShox BoXXer Select RC features a DebonAir damper, with rebound and low-speed compression adjustment so you can create your perfect setup.
A DH-specific 7-speed SRAM GX drivetrain takes care of shifting and is a proven bombproof performer. Shimano MT520 4-piston brakes keep things under control with 203mm rotors at both ends.
RaceFace rims are wrapped in Maxxis DHRII tyres, with 35mm finishing kit to match, making this a superb all-round package.
Please note - the Saracen Myst does not come supplied with pedals. Add some from our gear store!
-
DETAILS
- Variant: Medium
- Weight: 16.9 kg
Series 3 custom butted and hydroformed 6013 alloy
ALUMINIUM FRAME
211mm
FRAME TRAVEL
200mm
FORK TRAVEL
Mullet 29'' front 27.5'' rear
WHEEL SIZE
RockShox Boxxer Select RC
FORK
Marzocchi Bomber CR
SHOCK
1 x 7 SRAM GX DH
DRIVETRAIN
Full Specifications
-
FRAME: SERIES 3 CUSTOM BUTTED AND HYDROFORMED 6013, OPTIMISED FACTORY RACING SIZING
Headtube
Custom headtube with adjustable front offset plus-minus 5mm
Bearings
37mm main pivot bearings / 28mm linkage bearings
Linkage
CNC custom mullet links
Suspension
Signature TRL suspension design
Cable Routing
Internal cable routing and integrated fork bump-stops
Axle
12 x 157mm rear axle
Rear Travel
211mm
-
FORK: ROCKSHOX BOXXER SELECT RC
Travel
200mm
Technology
DebonAir / low speed compression / rebound adjust
Axle
20x110 Maxle Stealth DH
-
REAR SHOCK: MARZOCCHI BOMBER CR
Adjustment
Low speed compression / Rebound
Spring Weight
400lbs/in
Length / Stroke
250 x 75
-
CHAINSET: SRAM DESCENDANT
Model
DH
Chain Ring
34T
Crank Length
165mm
- BOTTOM BRACKET: SHIMANO BB52 83MM
-
SHIFTERS: SRAM GX
Model
DH
Speed
1x7 speed
-
REAR DERAILLEUR: SRAM GX
Model
DH
Speed
7 speed
- CHAIN DEVICE: MRP G4 CS
-
CASSETTE: SRAM PG720
Speed
7 speed
Ratio
11-25T
- CHAIN: KMC X11
-
BRAKES: SHIMANO BR-MT520
Brake Type
Hydraulic four piston
Rotor Size
203/203mm
- BRAKE LEVERS: SHIMANO BL-MT501
-
HUBS: FORMULA/KT
Front
DHL-93 sealed bearing 32H
Rear
KT M5HR sealed bearing 32H
Brake Fitting
6-bolt
Front Axle Type
20mm thru axle
Rear Axle Type
12 x 157mm Saracen Taper-Lock
Hole
32H
-
RIMS: RACEFACE ARC
Hole
32H
Size
29'' front / 27.5'' rear
Tubeless Ready
Yes
- SPOKES: DOUBLE-BUTTED STAINLESS STEEL
-
TYRES: MINION DHRII
Model
3CMaxxGrip DH TR
Size
29 x 2.5 front / 27.5 x 2.5 rear
-
HANDLEBARS: RACEFACE CHESTER ALLOY
Width
780mm
Rise
20mm
Bend
5 degree up bend / 8 degree sweep
Bar Bore
35mm
-
STEM: RACEFACE CHESTER
Length
50mm
Clamp
35mm
Type
Direct mount
- HEADSET: CUSTOM SARACEN HEADSET / 0MM OFFSET INSTALLED
-
SEAT POST: RACEFACE CHESTER
Size
30.9mm
Length
325mm
- SADDLE: SARACEN CUSTOM DH CRMO MTB
- GRIPS: ODI ELITE MOTION
- EXTRAS: CUSTOM CHAINSTAY PROTECTOR
- COLOUR: BLUE
166
168
170
172
174
176
178
180
182
184
186
188
190
192
194
196
Please be advised that this sizing chart is designed as a rough guide to help you select the size you require. Although height is one key factor on choosing the correct size bike, there are others which are discussed in our in-depth size guide feature.
Geometry
- 1251MM
- Wheelbase
SEAT TUBE |
410mm |
|---|---|
TOP TUBE |
607mm |
FRAME REACH |
455mm |
FRAME STACK |
615mm |
HEAD TUBE |
90mm |
HEAD ANGLE |
63.0° |
SEAT ANGLE |
76.5° |
CHAINSTAY |
450mm |
BB DROP |
9mm |
WHEELBASE |
1271mm |
SEAT TUBE |
410mm |
TOP TUBE |
641mm |
FRAME REACH |
485mm |
FRAME STACK |
624mm |
HEAD TUBE |
100mm |
HEAD ANGLE |
63.0° |
SEAT ANGLE |
76.5° |
CHAINSTAY |
450mm |
BB DROP |
9mm |
WHEELBASE |
1306mm |
SEAT TUBE |
410mm |
TOP TUBE |
661mm |
FRAME REACH |
505mm |
FRAME STACK |
633mm |
HEAD TUBE |
110mm |
HEAD ANGLE |
63.0° |
SEAT ANGLE |
76.5° |
CHAINSTAY |
450mm |
BB DROP |
9mm |
WHEELBASE |
1326mm |
